Sockets and Boom Pendants
SOCKETS AND BOOM PENDANTS
FEATURES
Abrasion Resistant
Low Stretch
Made in USA
Low Tolerance
Wire Rope Socket Assemblies
I&I Sling is one of the few companies that specializes in swaged and poured wire rope socket assemblies. Also known as socket lines or pendant lines these products provide a permanent hardware connection to the end of the wire rope. These assemblies can be made with extremely tight length tolerances, +/- ¼”. Available in both open and closed configurations, socket assemblies allow up to a 100% efficiency rating of the catalog strength of the wire rope. Sockets assemblies are commonly used for boom pendants, mooring, towing and static lines.
SEE CHARTEQUALIZER BLOCK
GENERAL INFOUSE AND CARE
LEARN MORESNATCH BLOCKS
VIEW DETAILSSwage Sockets are fabricated in-house by pressing the socket permanently to the end of the wire rope. This process is only recommended for use with 6×19 or 6×37 wire rope.
S501
S502
Poured sockets or spelter sockets are made by pouring a resin inside the socket to secure the wire to the socket. These sockets typically allow any type of wire to be used.
G416
G417
| Rope Diameter (in.) | Breaking Strength (Tons) | Capacity (Tons) |
| 1/2 | 13.3 | 2.6 |
| 9/16 | 16.8 | 3.3 |
| 5/8 | 20.6 | 4.1 |
| 3/4 | 29.4 | 5.8 |
| 7/8 | 39.8 | 7.9 |
| 1 | 51.7 | 10.3 |
| 1-1/8 | 65 | 13 |
| 1-1/4 | 79.9 | 15.9 |
| 1-3/8 | 96 | 19 |
