Ultrex Plus
Ultrex Plus
Ultrex Plus is a double braid constructed of an inner load bearing core of bio-based SK78 Dyneema® fiber, treated with Maxijacket coating for enhanced toughness.
Sleeved with high-tenacity polyester, Ultrex Plus is spliceable, using conventional high-modulus splice techniques or the new Yale tuck splice, which shortens the bury portion and minimizes the length of the larger diameter associated with a bury-type splice.
Ultrex Plus Splicing Instructions
Approved Splice Technique: #10015106, #10018007.
High Performance Double Braid – Eye Splice
High Performance Double Braid – Core Braid Back Splice
Ultrex Plus Specifications and Data
* Knots and abrupt bends significantly reduce the strength of all ropes and lower the maximum working load.
** Working load is based on static or moderately dynamic lifting/pulling operations. Instantaneous changes in load, up or down, in excess of 10% of the rope’s rated working load constitute hazardous shock load and would void the normal working-load recommendation. Consult Yale Cordage for guidelines for working loads and the safe use of rope.
Specific Gravity: 1.18
Dielectric Strength: The maximum allowable leakage for clean, dry Ultrex Plus is 100 micro-amperes when tested at 100kV per Yale Method 712-1701 Rev 1 "Routine Production Test." Absorbed and entrained moisture or impurities will increase rope’s conductivity dramatically.
